BESS储能
工商业储能可左右滑动查看
| BESS储能 | ||||||||||
| 参数 / 型号 | 2.5MW/2.5MWh-1C | 3MW/1.5MWh-2C | 2.5MW/5MWh-0.5C | 3MW/6MWh-0.5C | 3.34MW/6.68MWh-0.5C | |||||
| 模组 | 电芯 | 100Ah | 280Ah | 60Ah | 100Ah | 280Ah | 280Ah | 100Ah | 280Ah | 280Ah |
| 循环寿命 | 8000@25℃@1C | 8000@25℃@1C | 4000@25℃@2C | 8000@25℃@0.5C | 8000@25℃@0.5C | 8000次@25℃@0.5C | 8000次@25℃@0.5C | 8000次@25℃@0.5C | 8000次@25℃@0.5C | |
| 模块成组 | 3P14S | 1P14S | 2P20S | 3P18S | 1P16S | 1P48S | 3P16S | 1P16S | 1P52S | |
| 模块电压 | 44.8V | 44.8V | 64V | 57.6V | 51.2V | 153.6V | 51.2V | 51.2V | 166.4V | |
| 模块能量 | 13.44kWh | 12.544kWh | 7.68kWh | 17.28kWh | 14.336kWh | 43kWh | 15.36kWh | 14.336kWh | 46.59kWh | |
| 尺寸（立放L×W×H） | 290×689×358mm | 420×645×235mm | 290×658×280mm | 290×860×358m | 420×765×235mm | 790×1160×245mm | 290×775×358mm | 420×765×235mm | 790×1160×245mm | |
| 电池簇 | 模块数量 | 16pcs | 17pcs | 12pcs | 21pcs | 25pcs | 8pcs | 22pcs | 24pcs | 8pcs |
| 标称电压 | 716.8V | 761.6V | 768V | 1209.6V | 1280V | 128.8V | 1126.4V | 1228.8V | 1331.2V | |
| 电压范围 | 627-795V | 666-845V | 672-852V | 1058.4-1341.9V | 1120-1420V | 1074-1363V | 1003-1249V | 1075-1363V | 1164-1476.8V | |
| 单簇电量 | 215.04kWh | 213.24kWh | 92.16kWh | 362.88kWh | 358.4kWh | 344kWh | 337.92kWh | 344kWh | 372.73kWh | |
| 尺寸（L×W×H） | 1200×689×2350mm | 1050×645×2350mm | 900×671×2200mm | 1400×860×2350mm | 1500×765×2350mm | 890×1160×2510mm | 1400×775×2350mm | 1500×765×2350mm | 890×1160×2510mm | |
| 单簇最大模块数量 | 17pcs | 17pcs | / | 23pcs | 26pcs | 8pcs | 23pcs | 26pcs | 8pcs | |
| 单簇最大电量 | 228.48kWh | 213.24kWh | 92.16kWh | 397.44kWh | 372.7kWh | 344kWh | 353.28kWh | 372.7kWh | 372.73kWh | |
| 集成舱 | 电池簇数量 | 12pcs | 12pcs | 18pcs | 14pcs | 14pcs | 18pcs | 10pcs/单舱 | 10pcs/单舱 | 18pcs |
| 单簇能量 | 215.04kWh | 213.24kWh | 92.16kWh | 362.88kWh | 358.4kWh | 344kWh | 337.92kWh/单舱 | 344kWh/单舱 | 372.73kWh | |
| 电池系统电量 | 2.58MWh@40尺 | 2.558MWh@40尺 | 1.658MWh@40尺 | 5.018MWh@45尺 | 5.018MWh@45尺 | 6.19MWh@40尺 | 3.379MWh@40尺×2舱 | 3.44MWh@40尺×2舱 | 6.709MWh@40尺 | |
| 对应PCS | 630kW×4 | 630kW×4 | 500kW×6 | 2500kW×1 | 2500kW×1 | 1550kW×2 | 1670kW×2舱 | 1670kW×2舱 | 1675kW×2 | |
| 电池系统发热功率 | ＜80kW | ＜80kW | ＜67kW | ＜60kW | ＜60kW | ＜51.7kW | ＜34kW | ＜34kW | ＜56kW | |
| 最大簇数量 | 15pcs | 15pcs | 18pcs | 14pcs | 14pcs | 18pcs | 12pcs/单舱 | 12pcs/单舱 | 18pcs | |
| 最大电量 | 3.427MWh | 3.198MWh | 1.658MWh | 5.564MWh | 5.218MWh | 6.19MWh | 4.239MWh/单舱 | 4.472MWh/单舱 | 6.709MWh | |
| 冷却方式 | 风冷 | 风冷 | 风冷 | 风冷 | 风冷 | 液冷 | 风冷 | 风冷 | 液冷 | |
| 防护等级 | IP54 | IP54 | IP54 | IP54 | IP54 | IP54 | IP54 | IP54 | IP54 | |
